Picture for reference:

Main technical parameter:

Model: XT-125

Packing speed: 40-100boxes/min

Packing dimension: L: 49-120  W: 30-80  H: 14-50

Air consumption: 5-8L/min

Total power: 1.5KW

Voltage: 220V/380V/50Hz

Boundary dimension: 1300*1200*1500(L*W*H)

Weight: 950Kg

Main electrical components list:

Working process of the box packing machine:

The empty box is sucked down by vacuum, and then opened, the leaflet is folded at the same time(one fold to four folds, you can choose at will), to the second working station, the machine will put the finished eye drop bottle and leaflet to the opened box, to the third working station, it will automatic print batch number, and then finished the box packing.

Main performance features:

1. Compact structure, easy operation and convenient maintenance.
2. Wide application and adjustment range, low requirement to packing materials.
3. Convenient specification adjustment, no need to change spare parts.
4. Sensitive and reliable checking, high qualified rate.
5. Low power consumption, less operators need.
6. Adopts PLC automatic control system, frequency adjusting speed.
7. Human-machine touch screen control system, automatic display manufacturing speed and total output.
8. It has manual and automatic selection function.

It can realize many specification adjustment, no need to change the spare parts, at the same time, it can print the batch number at the same time, convenient to use.

It can realize automatic fold the leaflet, 1-4 fold, you can choose at will.

It has automatic detection system, can automatic detect whether there is bottle and leaflet, if has no bottle or no leaflet, it will automatic positioned to stop or automatic eliminating.
